2.3.2 Working with suppliers Pindrop

Target Level

4-5

Running Total

Attempt

1 of 3

Click on a top label, then click on its correct position on the diagram. Or, drag a top label and drop it onto the correct position. Position all the labels before clicking ‘Check’.

This is a bar gate diagram. You will not need to draw one in an exam, but you might need to be able to read one. Can you label the diagram correctly?

250

750

Buffer stock level

500

BAR GATE STOCK GRAPH

Number of weeks

Stock level (in kg)

Maximum stock level

Reorder level

This is your 1^st attempt! You get 3 marks for each one you get right. Good luck!

Pass Mark

80%
