Click on an item, then click on a category to place it. Or, drag and drop the item into the correct category. Organise all items before clicking 'Check'.

Categorise the combinations of inputs according to whether they would result in an output of 'true' or 'false', according to the logic circuit shown.

True

False

a = false; b = true; c = false

a = true; b = true; c = true

a = true; b = false; c = true

a = true; b = false; c = false

a = false; b = false; c = true

a = false; b = true; c = true

a = true; b = true; c = false

a = false; b = false; c = false
